Tobee® M Medium Slurry Pump

Good quality Vertical Slurry Pump for sales
Good quality Vertical Slurry Pump for sales
I'm Online Chat Now

Tobee® M Medium Slurry Pump

China Tobee® M Medium Slurry Pump supplier
Tobee® M Medium Slurry Pump supplier Tobee® M Medium Slurry Pump supplier Tobee® M Medium Slurry Pump supplier Tobee® M Medium Slurry Pump supplier

Large Image :  Tobee® M Medium Slurry Pump

Product Details:

Place of Origin: Hebei
Brand Name: TOBEE PUMP
Certification: ISO,CE,SGS
Model Number: M Medium Slurry Pump

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Wooden case
Delivery Time: 7 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5800
Contact Now
Detailed Product Description
Size: 8" To 10" Capacity: 540-1440 M3/h
Head: 14-60 M Handing Solids: 0-65mm
Materials: Hyper Chrome Alloy, Rubber, Polyurethane, Ceramic, Stainless Steel Etc. Type: M Slurry Pump
Model: M Horizontal Slurry Pump Uasge: Minerals Processing, Cyclone Feed To Regrind, Flotation And Tailings.

 Tobee® M Medium Slurry Pumps are the most comprehensive range of centrifugal slurry pumps for use in mining, chemical and general industry applications. The horizontal slurry pumps are designed for heavy duty applications such as mill discharge, power sector and tailings as well as specialty applications, which are used for continuous pumping of high abrasive, high density slurries.



Size: 8" to 10"
Capacity: 540-1440 m3/h
Head: 14-60 m
Handing solids: 0-65mm
Concentration: 0%-70%
Materials: Hyper chrome alloy, Rubber, Polyurethane, Ceramic, Stainless steel etc.


Detailed specification:

1. Horizontal, cantilevered, centrifugal, single stage slurry pump.

2.Long bearing life: The bearing assembly is with large diameter shaft and short overhang.

3. Wear resistant and anti abrasion wet parts: High chrome alloy and rubber etc. They are completely interchangeable with each other.

4. Easily replaceable liners: Liners are bolted to the casing.

5. Easy adjustment of impeller: An impeller adjustment mechanism is provided below the bearing housing.

6 Discharge direction can be positioned at intervals of 45 degrees.

7. Simple maintenance throat bush: the mating face of the throat bush is tapered, so the wear is reduced and removal is simple.

8. Sealing type: pcking seal,impeller sealing and mechanical seal.

9. Widely application: They are designed for handling abrasive, high density slurries in the metallurgical, mining, coal, power, building material and other industrial departments.


Tobee® M Medium Slurry Pump Performance Parameter:



Max. Power


Material Clear Water Performance Impeller

Capacity Q


Head H


Speed n


Eff. η




Vane No.
10/8E-M 300 M 666~1440 14~60 600~1100 73 4~10 5
RU 540~1188 10~42 500~900 79 5~9
10/8R-M 120 M 666~1440 14~60 600~1100 73 4~10 5
  RU 540~1188 10~42 500~900 79 5~9
12/10E-M 120 M 936~1980 7~68 300~800 82 6 5
  RU 720~1620 7~45 300~650 80 2.5~7.5


Tobee® M Medium Slurry Pump Component Diagram:

Tobee® M Medium Slurry Pump


Tobee® M Medium Slurry Pump Structural Drawing:

Tobee® M Medium Slurry Pump


Tobee® M Medium Slurry Pump Shaft Seal:


Packing seal:

As one of the most commonly used seals for rotating shafts, the packing seal can come with low-flush or full flush arrangement which uses flushing water to prevent media from escaping the pump housing. This kind of seal is suitable for use under all pumping conditions. In situations where corrosive solids or high temperature might be encountered, Teflon or aramid fiber is used as the packing material for the gland. For high abrasion conditions, a ceramic shaft sleeve is available.

Expeller seal:

The combination of impeller and expeller creates the pressure needed to seal against leakage. Together with the gland seal or lip seal which is used as the shut-down seal, this type of seal can handle sealing requirements for applications where full-flush gland seal is impractical due to lack of water on the site, or sealing water is allowed to enter inside the pumping chamber to dilute the slurry.

Mechanical seal:

TH series heavy duty slurry pump utilizes a leak-proof mechanical seal design which allows easy installation and replacement. Other types of mechanical seal are among options to suit the slurry pump for various pumping applications.


Tobee® M Medium Slurry Pump Drive Type

Tobee® M Medium Slurry Pump


Tobee® M Medium Slurry Pump Quality Control:

Stages of manufacture Quality cotrol activities
Raw material arrival Sampling, material chemical analysis
Casting and composition Material material chemical analysis of pump parts
Casting quality inspection
Key component machining Dimension precision inspection
Impeller balancing
General assembly Procedure operaion
Hydraulic static test
Performance test of pump unit Capacity and head
Vibration and noise
Bearing temperature
Final inspection Packaging of pump unit
Spare parts and accessories





















Tobee® M Medium Slurry Pump After-sales Service:


As the slurry pump wet ends parts such as the impeller,volute liner,FPL insert,Throat bush are consumption parts and we could provide you always the qualified slurry pump parts within very short time.


Packing Transport Services

Considering the order pump size and we could provide case or pallet as per your need to make sure it safe enough during the long distance road and ocean shipping.have its own export company and so we could help you find the best ocean shipping solution and service for you from the goods out of factory to your destination.

Installation Services

Tobee Pump have more than 30 years experienced pump installation workers and are very aware of any onside application.We could provide abroad pump installation service and expect pump manufacturing and sales,abroad pump installation is getting more and more popular by our regular clients abroad.

Technical Support Services

Technical data sheet,Performance curve,General arrangement drawing,Operating manual will be sent within 24th for your checking, So Pls feel free to contact us If you have any need.


Tobee® HH High Head Slurry Pump On-Site Application:

Tobee® M Medium Slurry Pump

1)Mine:Black, non-ferrous ore slurry material pump and all kinds of concentrate and tailings conveying.

2)Metallurgy:Transport various slurry for aluminium or steel manufacture.

3)Coal: Coal mining, washing and various coarse and fine coal slurry transportation.

4)Electricity:Remove power plant ash,wash ash,various ash dregs or ash slurry transportation.

5)Construction materials:Various mud sand slurry(such as Cement slurry) transportation.

6)Chemical: Phosphatic fertilizer or potassic fertilizer factory various abrasive slurry trasportation.

7)Water conservancy:Lake,river dredge, sediment,grit, High plastic clay Suction line to transportation.


Tobee® M Medium Slurry Pump:

Tobee® M Medium Slurry Pump



1.Q:Are you a factory or trading company?
A:We are a big manufacturing pump factory with 30 years experience.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Shijiazhuang City, Hebei Province, China.You can fly to Shijiazhuang airport directly.All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:What is The material of your pumps?
A: The materials can be selected by High chrome alloy or Rubber,Polyurethane,Cast iron,SS304,SS316,CD4MCu,Duplex SS,Bronze etc. We can also choose material as customers’ requirement.
4.Q:How can I get some samples?
A: We are honored to offer you samples.
5.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end. Our factory has 15~20QC.
